Audiomatus power amplifiers based on ICEpower® technology
Model AM250R - RCA input, AM250X - XLR input monoblock amplifiers|
Output power |
130 W / 8 Ω 250 W / 4 Ω 300 W / 2.7 Ω |
|
THD+N @ 4 Ω / f=1 kHz / Po=1 W |
0.0055% |
|
IMD CCIF 14 kHz, 15 kHz Po=10 W |
0.0009% |
|
Dynamic range @ 250 W / 4 Ω |
AM250R 108dB AM250X 112dB |
|
Frequency response |
5 Hz - 80 kHz |
|
Damping factor @ 1 kHz / 8 Ω |
1000 |
|
Input sensitivity @ 250 W / 4 Ω |
AM250R 0,75V AM250X 1,50V |
|
Input impedance |
AM250R 100kΩ AM250X 8,2kΩ |
|
Efficiency Po=200 W @ 4 Ω |
82.5% |
|
Power consumption |
|
|
Weight |
4.8 kg |
|
Dimensions (w x h x d) |
8.46 x 3.39 x 15.9 in |
AM250R AM500R back image
Model AM500R - RCA input, AM500X - XLR input monoblock amplifiers
|
Output power |
290 W / 8 Ω 580 W / 4 Ω |
|
THD+N @ 4 Ω / f=1 kHz / Po=1 W |
0.006% |
|
IMD CCIF 14kHz, 15kHz Po=10 W |
0.0005% |
|
Dynamic range @ 500 W / 4 Ω |
AM500R 112 dB AM500X 115dB |
|
Frequency response |
5 Hz - 80 kHz |
|
Damping factor @ 1 kHz / 8 Ω |
1000 |
|
Input sensitivity @ 500 W / 4 Ω |
AM500R 1,00V AM500X 2,00V |
|
Input impedance |
AM500R 100kΩ AM500X 8,2kΩ |
|
Efficiency Po=500 W @ 4 Ω |
81 % |
|
Power consumption |
|
|
Weight |
5.4 kg |
|
Dimensions (w x h x d) |
8.46 x 3.39 x 15.9 in |
High-end sound. Affordable price.
